STANDARD SPECIFICATIONS
GVWR: 16,680 lbs.
Empty Weight: 2,680 lbs.
Maximum Payload: 14,000 lbs. W/ adequate hitch load
Overall Length: 25′
Deck Length: 18′ (14.9 flat w/ 3’3″ beavertail)
Overall Width: 102″
Deck Width: 82″
Deck Height: 27″
Loading Ramp: 4′ Cleated Fully Adjustable
Hitch: Adjustable 2 1/2″ Eye
Hitch Height: 24″ to 32″
Fenders: Diamond Plate
Axles: (2) 7,000 lb. w/ Brakes
Suspension: Multi-Leaf Spring
Brakes: Electric w/ 12″ x 2″ w/ break-a-way
Wheels: 16″ x 6″ Single 8-bolt
Tires: ST235/80R16″ 10-PR
Jack Capacity: 7,000 lb. w/adjustable foot
Main Frame: 7″ Channel @ 9.8# (turned out)
Crossmembers: 3″ channel @ 3.5#
Decking: 2″ X 8″ Treated Pine
Tie Downs: Stake Pockets
Lights: DOT Approved Lighting
Colors: Yellow or Black
